Gear Design 3D in TrueGeometry

Features Gear Design 3D in TrueGeometry

Design, iterate, simulate Gears and Cams.
Generate 3D models for manufacturing.Features:1.
Gear 3D Generation2.
Gear 2D generation3.
Cam and Follower 3D generation4.
Cam and Follower 2D generation with displacement diagram5.
Herringbone gear 3D6.
Rack & Pinion 3D7.
Basic Geometric shapes 3D8.
Superchargers8.
Sharing of 3D data9.
Sharing of 2D data10.
Remembers the last edited value of each design.11.
ASME Flanges12.
BIS Beams13.
Unit Conversion14.
Fluid and Solid density table,15.
Tank Volume CalculationLearn from : https://blog.truegeometry.com/tutorials/appIntroductionf3U.htmlExport formats for Geometry: OBJ,PLY,STL,DAE, GLB & GLTFThe app provides a gateway to generate true geometry from engineering to free form shapes, on your mobile and computer.
The geometry created can be used to print 3D models via 3D Printers.
The geometry created can be imported to any 3D software application, including Microsofts "3D Viewer".One time purchase gives access to unlimited design generation and sharing.
However this subjected to computing cost.
